Apartment Access Control Flap Barrier Turnstile 304 Stainless Steel 1400 * 280 * 980mm

Name: Apartment Access Control Flap Barrier Turnstile 304 Stainless Steel 1400 280 980mm
Brand: Jiaxuntong
Price: 1 USD

Brand Name : Jiaxuntong

Model Number : CF238FLG-YJ

Certification : CE

Place of Origin : Made In China

MOQ : 1 set

Supply Ability : 300 per month

Packaging Details : wooden case

Materials : 304 stainless

product name : Flap Barrier

Anti-reverse : Anti-reverse function in order to ensure one card for one person

Lane Frame : National standard 1.5mm thickness brushed satin 304 stainless steel

Application : School

Housing Size : 1400*280*980

Contact Now

Biometric Automatic Apartment Access Control Barrier Gate Flap Barrier

Technical parameters

1	Power	AC220V±20%V,50Hz
2	Relative Humidity	0-95%
3	Working Temperature	-40ºC--70ºC
4	Passing Speed	35 persons/min
5	Communication Interface	Rs485(Distance less than 1200m)
6	Framework Material	304 or 316 stainless steel
7	Working environment	indoor/ outdoor
8	Service Life	4.5 million times
9	Gate Turn/Off time	≤ 0.4S
10	Infrared Sensors	9 or 10 pairs
11	Color	Stainless Steel Brushed /Powder Coating
12	Protect Level	IP54
13	Motor Operation Speed	1600R/Min
14	Input Connection	+12V Level Signal or Pulse Wide>100ms Pulse Signal,Current>100ms
15	Manufacturing Technique	CNC laser cutting
16	Operation Place	Subway Station,Hotel,Tourism Public Park ,Exhibition,Swimming Hall and so on

Features

1, Mechanical anti-pinch function:More safer and easier for control.
2, Led Indicator Light
3, Alarm function:To remind the passer to used IC card reader or in case some illegal behavior .
4, Anti-breakthrough function:If someone not use the IC card reader ,then the gate will locked .
5, One time just one people can go through.
6, Passing Reading Model: IC / ID card readers, bar codes, fingerprints, etc
7,The Remote Control Function:Can inset the RS485 card to control the gate.
8, Automatic reset function:If fail to passing within the regulated time (1-60 sends),the gate will locked.
